4. Using the Viewer
❺ Projecting data from media server
LAN
Media server
Media server
WirelessLAN
Media server
Projector
Preparation
Forprojector:Connecttheprojectortothenetwork.
Forcomputer:Prepareimagelesormovielestobeprojected,andsetup“MediaSharing”inWindowsMediaPlayer
11orWindowsMediaPlayer12.
NOTE:
• Boththeprojectorandthemediaservermustbeonthesamesubnet.Connectingtothemediaserverbeyondthesubnetisnot
possible.
• TypesofimagesandmovieswhichcanbesharedmayvarydependingonWindowsversion.
Setting up “Media Sharing” in Windows Media Player 11
1. StartWindowsMediaPlayer11.
2. Select“MediaSharing”from“Library”.
The“MediaSharing”dialogboxwillbedisplayed.
