210
9. Appendix
Projection range for the different lenses
80-200"
100-500"
100-500" 100-500"
50-300"
NP25FL : 1.1–3.2 m
NP26ZL : 2.8–24.0 m
NP27ZL : 4.0–24.0 m
NP28ZL : 9.0–45.0 m
NP29ZL : 12.0–80.0 m
