84
4. Using the Viewer
•SORTSETTING
Setstheorderofdisplayingthumbnailsorslides.
Name Options Description
SORT NAME(ABC..) Displaysthelesalphabeticallybynameinascendingorder.
NAME(ZYX..) Displaysthelesalphabeticallybynameindescendingorder.
EXT.(ABC..) Displaysthelesalphabeticallybyextensioninascendingor-
der.
EXT.(ZYX..) Displays the les alphabetically by extension in descending
order.
DATE(NEW) Displaysthelesinreversechronologicalorder.
DATE(OLD) Displaysthelesinchronologicalorder.
SIZE(BIG) Displaysthelesindescendingorderofitslesize.
SIZE(SMALL) Displaysthelesinascendingorderofitslesize.
