204
8. User Supportware
Operating the Projector Via the LAN (Virtual Remote Tool)
Usingthesoftwareprogram“VirtualRemoteTool”thatyoucandownloadfromourwebsite,VirtualRemotescreen
(ortoolbar)canbedisplayedonyourcomputerscreen.
Thiswillhelpyouperformoperationssuchasprojector’spoweronoroffandsignalselectionviaaLANconnection.It
isalsousedtosendanimagetotheprojectorandregisteritasthelogodataoftheprojector.Afterregisteringit,you
canlockthelogotopreventitfromchanging.
Control Functions
PowerOn/Off,signalselection,picturefreeze,picturemute,Logotransfertotheprojector,andremotecontrolop-
erationonyourPC.
VirtualRemotescreen
RemoteControlWindow Toolbar
ThissectionprovidesanoutlineofpreparationforuseofVirtualRemoteTool.
ForinformationonhowtouseVirtualRemoteTool,seeHelpofVirtualRemoteTool.(→page206)
NOTE:
• Logodata(graphics)thatcanbesenttotheprojectorwithVirtualRemoteToolhasthefollowingrestrictions:
- Filesize:256KBorless
- Imagesize(resolution):thenativeresolutionofthe projector
- Fileformat:JPEG
• ThelogodatathatissentwithVirtualRemoteToolwillbedisplayedatthecenterofthescreen.Itssurroundingwillbepainted
out in black.
• Onceyouhavechangedthebackgroundselectionfromthedefault“NEClogo”toanotherselection,youcannotreturnthelogoto
thedefault“NEClogo”evenafterusing[RESET].Toputthedefault“NEClogo”backinthebackgroundlogo,youneedtoregister
itasthebackgroundlogobyusingtheimagele(\Logo\NEC_logo_black_WUXGA.jpg)includedonthesuppliedNECProjector
CD-ROM.
TIP:
• VirtualRemoteToolcanbeusedalsowithaserialconnection.
• TodownloadorupdateVirtualRemoteTool,visitourwebsite:http://www.nec-display.com/dl/en/index.html
Connect the projector to a LAN.
ConnecttheprojectortotheLANbyfollowingtheinstructionsin“ConnectingtoaWiredLAN”(→page167),“Con-
nectingtoaWirelessLAN(soldseparately)”(→page168)and“9ApplicationMenus-NETWORKSETTINGS”(→
page136)
