170
6. Installation and Connections
To remove the wireless LAN unit
1. Pressthe buttontosettheprojectortothestandbymode,then
turnoffthemainpowerswitch.
2. Removetheanti-theftcap.
Loosenthescrewandremovetheanti-theftcapfortheWirelessLAN
Unit.
3. PullouttheWirelessLANUnitfromtheUSB(LAN)port.
NOTE:
IfthewirelessLANunitisnottobeusedforanextendedperiodoftime,putthe
plate back and secure it with the two screws.
