6. Installation and Connections

DisplayPort IN

HDMI IN

Digital RGB signal connection

• ConnectacommerciallyavailableHDMIcablebetweenthecomputer’sHDMIoutputconnectorandtheprojector’s

HDMIinputconnector.

• ConnectacommerciallyavailableDisplayPortcablebetweenthecomputer’sDisplayPortoutputconnectorand

theprojector’sDisplayPortinputconnector.

• Selectthesourcenameforitsappropriateinputconnectorafterturningontheprojector.

Inputconnector

SOURCEbuttonontheprojector

cabinet

Buttonontheremotecontrol

HDMIIN HDMI HDMI

DisplayPortIN DisplayPort DisplayPort

NOTE:

• Turnoffthepowerofthecomputerandprojectorbeforeconnecting.

• ThisprojectordoesnotsupportNECvideounit(modelISS-6020)videodecoded outputs.

• When a video deck is connected via a scan converter, etc., the display may not be correct during fast-forwarding and

rewinding.

TIP

• TheComputer1andComputer2videoinputconnectorssupportWindowsPlugandPlay.TheComputer3videoinputconnector

doesnotsupportWindowsPlugandPlay.

• AMacintoshsignaladapter(commerciallyavailable)mayberequiredtoconnectaMacintoshcomputer.

 ToconnectaMacintoshcomputerequippedwithaMiniDisplayPorttotheprojector,useacommerciallyavailableMiniDisplayPort

→DisplayPortconvertercable.

HDMIcable(notsupplied)

DisplayPortcable(notsupplied)
