Nec PX700W [136/244] Installation 2

122

5. Using On-Screen Menu

[INSTALLATION(2)]

Disabling the Cabinet Buttons [CONTROL PANEL LOCK]

ThisoptionturnsonorofftheCONTROLPANELLOCKfunction.

NOTE:

• ThisCONTROLPANELLOCKdoesnotaffecttheremotecontrolfunctions.

• Whenthecontrolpanelislocked,pressingandholdingtheEXITbuttonontheprojectorcabinetforabout10secondswillchange

thesettingto[OFF].

TIP:Whenthe[CONTROLPANELLOCK]isturnedon,akeylockicon[ ]willbedisplayedatthebottomrightofthemenu.

EnablingSecurity[SECURITY]

ThisfeatureturnsonorofftheSECURITYfunction.

Unlessthecorrectkeywordisentered,theprojectorcannotprojectanimage.(→page45)

NOTE:Yoursettingwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

Selecting Communication Speed [COMMUNICATION SPEED]

ThisfeaturesetsthebaudrateofthePCControlport(D-Sub9P).Itsupportsdataratesfrom4800to115200bps.

Thedefaultis38400bps.Selecttheappropriatebaudrateforyourequipmenttobeconnected(dependingonthe

equipment,alowerbaudratemayberecommendedforlongcableruns).

NOTE:

• Select[38400bps]orlesswhenusingtheUserSupportware.

• Yourselectedcommunicationspeedwillnotbeaffectedevenwhen[RESET]isdonefromthemenu.

Turning On or Off Remote Sensor [REMOTE SENSOR]

Thisoptiondetermineswhichremotesensorontheprojectorisenabledinwirelessmode.

Theoptionsare:FRONT/BACK,FRONT,andBACK.

Iftheremotecontrolsystemdoesnotfunctionwhendirectsunlightorstrongilluminationstrikestheremotecontrol

sensoroftheprojector,changeanotheroption.

Setting ID to the Projector [CONTROL ID]

YoucanoperatemultipleprojectorsseparatelyandindependentlywiththesingleremotecontrolthathastheCONTROL

IDfunction.IfyouassignthesameIDtoalltheprojectors,youcanconvenientlyoperatealltheprojectorstogether

usingthesingleremotecontrol.Todoso,youhavetoassignanIDnumbertoeachprojector.

CONTROL ID NUMBER ��Select a number from 1 to 254 you wish to assign to your projector�

CONTROL ID ��Select [OFF] to turn off the CONTROL ID setting and select [ON] to turn on the CONTROL ID set-

ting�
