Nec PX700W [172/244] Installation and connections
![Nec PX700W [172/244] Installation and connections](/views2/1015907/page172/bgac.png)
158
6. Installation and Connections
(2)Makesurethatthelensreleaseleverpointsupward(RE-
LEASE).
(3)Makesurethatthesafetyleverissettotheunlockedposi-
tion (UNLOCK) to prevent the lens from falling out.
UNLOCK
LOCK
RELEASE
LOCK
LENS
2
3
2. Removethelenscaponthebackofthelens.
• TheNP27ZLlensisusedasanexample.
NOTE:Mountingthelenswithlenscaponitsbacktotheprojectorcan
cause malfunction.
3. Placetheguidepininthecorrectorientationbyaligning
itwiththenotchonthelenshood,theninsertthelens
intotheprojector.
Pushthelensslowlyuntilitcomestoacompletestop.
Guidepin
Notch
4. Setthesafetylevertotherightposition(LOCK)tolock
thelens.
LOCK
LOCK
LENS
5. Slowlyturnthelensreleaselevercounterclockwiseuntil
thelensreleaseleverisfacingdownward.
• Ifthelensreleaselevercannotbeturned,itmeansthat
thelensisnotfullyinserted.
Turnbackthelensreleaselevertotheunlockedposition
and push the lens into the projector until it comes to a
complete stop.
