15
2. Projecting an Image (Basic Operation)
Removingthepowercordfromthepowercordstopper
1. Pushtheclamperofthepowercordstoppertounclaspit.
2. Pushthepowercordclampertoopenitwideenoughtopulloutthepowercord.
Clamper
