2. Projecting an Image (Basic Operation)
2. Pressthe (POWER)buttonontheprojectorcabinet
orthePOWERONbuttonontheremotecontrol.
ThePOWERindicatorwillturntoblueandtheprojector
willbecomereadytouse.
TIP:
• Whenthemessage“PROJECTORISLOCKED!ENTERYOUR
PASSWORD.” isdisplayed, it means that the [SECURITY]
featureisturnedon.(→ page 45)
• When the ECO message is displayed, it means that [ON]is
selectedfor[ECOMESSAGE].(→ page 117)
Afteryouturnonyourprojector,ensurethatthecomputer
or video source is turned on.
NOTE:Whennosignalisavailable,theNEClogo(default),blue,or
black screen will be displayed.
Standby Blinking PowerOn
Steady orange
light
Blinking blue
light
Steady blue
light
(→page222)
