177
7. Maintenance
4. Putthelterbackintoplace.
Insertthelterwith“↓AIRFLOW↓”facingtheprojector.
(1)Insertthelterintheinlet.
(2) Fitthetopedgeofthelterintheinlet.
Filter
5. Placetheltercoverbackintotheprojectorcabinet.
(1)Aligntheknob(screw)withthescrewhole.
(2)Tighteneachofthetwoknobsbyturningitclockwise.
1
2
Screwhole
Filter cover
6. Clearthelterusagehours.
Plugthepowercord intothe walloutlet,turn on themain
powerswitch,andthenturnontheprojector.
Fromthemenu,select[RESET]→[CLEARFILTERHOURS]
andresetthelterusagehours.(→ page 133)
