6. Installation and Connections

PartNamesandFunctionsofStackingColumn

Stackingcolumn

Upper projector

Totilttheupperprojectorhorizontally,usethelowerprojector’s

horizontaladjustmentknob.

Lower projector

Usethelowerprojector’shorizontaladjustmentknobtonelytiltthe

twoprojectorshorizontally.

Securitylockingpin(withawire)

Afterpullingoutfoursecuritylockingpins,puteachfootoftheupperprojectorhere,andthen

insertthefoursecuritylockingpinsfullysothatthefeetcannotmove.

Eachsecuritylockingpincanbeinsertedfromeitherdirection.

Foot holder

Place the four feet in their respective foot holder.

Horizontaladjustmentknob

Finelytilttheupperprojectorhorizontally.Turnitclockwisetoorienttheprojectortotheright;

turnitcounterclockwisetoorienttheprojectortotheleft.

Maximumrotatingangle:+/−0.4°

Vertical adjustment ring

Tilttheprojectorvertically.Turntheverticaladjustmentringclockwisetobeshortened;turnit

counterclockwisetobeextended.Ifyoucannotturnitmanually,useahexagonalwrench.Donot

turn the screws inside.

Upto38mm(1.5")canbeextended.

Foot(4locations)

Supporttheprojectoratthefourlocations.
