7. Maintenance
Replacing the filter on the front side
1. Removetheltercover.
(1)Looseneachofthetwoknobsbyturningthemcounter-
clockwise.
•Theknobsarenotremovable.
•If the knob is too tight to turn, use a Phillips screw-
driver.
(2)Removetheltercoverbypullingitout.
1
2
Knob
2. Removethelter.
Removethelterbypullingittotheright.
Filter
3. Installthenewlter.
Insertthelterwith“↓AIRFLOW↓”facingtheprojector.
(1)Insertthelterintheinlet.
(2) Fitthetopedgeofthelterintheinlet.
Filter
4. Placetheltercoverbackintotheprojectorcabinet.
(1)Aligntheknob(screw)withthescrewhole.
(2)Tighteneachofthetwoknobsbyturningitclockwise.
1
2
Screwhole
Filter cover
This completes the filter replacement.
Go on to the clearing lamp and filter hour meters.
