98
5. Using On-Screen Menu
SETUP
BASIC
KEYSTONE
HORIZONTAL 0
VERTICAL 0
CORNERSTONE
PIP/PICTUREBY
PIP/PBPMODE PIP PIP,PICTUREBYPICTURE
PIPPOSITION BOTTOM-RIGHT TOP-LEFT,TOP-RIGHT,BOTTOM-LEFT,BOTTOM-RIGHT
PIP/PBPSOURCE OFF OFF,VIDEO,S-VIDEO
WALLCOLOR OFF
OFF,BLACKBOARD,BLACKBOARD(GRAY),LIGHT
YELLOW,LIGHTBLUE,LIGHTROSE
LAMPMODE
ECOMODE OFF OFF,ON
LAMPSELECT DUAL DUAL,SINGLE,LAMP1ONLY,LAMP2ONLY
LAMPINTERVAL
MODE
OFF OFF,12HOURS,24HOURS,1WEEK
LAMPSWITCHING
TIME
00:00 00:00-24:00
LAMPSWITCHING
DAY
SUN SUN,MON,TUE,WED,THU,FRI,SAT
CLOSEDCAPTION OFF
OFF,CAPTION1,CAPTION2,CAPTION3,CAPTION4,
TEXT1,TEXT2,TEXT3,TEXT4
OFFTIMER OFF OFF,0:30,1:00,2:00,4:00,8:00,12:00,16:00
TOOLS
ADMINISTRATORMODE,PROGRAMTIMER,TIME,
MOUSE
LANGUAGE ENGLISH
ENGLISH,DEUTSCH,FRANÇAIS,ITALIANO,ESPAÑOL,
SVENSKA,日本語
DANSK,PORTUGUÊS,ČEŠTINA,MAGYAR,POLSKI,
NEDERLANDS,SUOMI
NORSK,TÜRKÇE,РУССКИЙ, , Ελληνικά, 中文, 한국어
ROMÂNĂ, HRVATSKA, БЪЛГАРСКИ, INDONESIA, हिन्दी,
ไทย
MENU
COLORSELECT COLOR COLOR,MONOCHROME
SOURCEDISPLAY ON OFF,ON
MESSAGEDISPLAY ON OFF,ON
IDDISPLAY ON OFF,ON
ECOMESSAGE OFF OFF,ON
DISPLAYTIME AUTO45SEC MANUAL,AUTO5SEC,AUTO15SEC,AUTO45SEC
BACKGROUND LOGO BLUE,BLACK,LOGO
FILTERMESSAGE OFF OFF,100[H],500[H],1000[H],2000[H],5000[H]
INSTALLATION
(1)
ORIENTATION
DESKTOP
FRONT
DESKTOPFRONT,CEILINGREAR,DESKTOPREAR,
CEILINGFRONT
SCREEN SCREENTYPE 4:3SCREEN 4:3SCREEN,16:9SCREEN,16:10SCREEN
GEOMETRICCORRECTION OFF OFF,1,2,3
MULTI-SCREEN
COMP.
MODE OFF OFF,ON
CONTRAST 0
BRIGHTNESS 0
REF.WHITE
BALANCE
CONTRASTR 0
CONTRASTG 0
CONTRASTB 0
BRIGHTNESSR 0
BRIGHTNESSG 0
BRIGHTNESSB 0
UNIFORMITYR 0
UNIFORMITYB 0
REF.LENS
MEMORY
STORE
MOVE
RESET
LOADBYSIGNAL
FORCEDMUTE
CALIBRATION
INSTALLATION
(2)
NETWORKSETTINGS
WIREDLAN,WIRELESSLAN,WPS,NETWORK
INFORMATION,PROJECTORNAME,DOMAIN,ALERT
MAIL,NETWORKSERVICE
CONTROLPANELLOCK OFF OFF,ON
SECURITY OFF OFF,ON
COMMUNICATIONSPEED 38400bps 4800bps,9600bps,19200bps,38400bps,115200bps
REMOTESENSOR FRONT/BACK FRONT/BACK,FRONT,BACK
CONTROLID
CONTROLID
NUMBER
1 1–254
CONTROLID OFF OFF,ON
* Theasterisk(*)indicatesthatthedefaultsettingvariesdependingonthesignal.
