8. User Supportware
Converting PowerPoint files to Slides (Viewer PPT Converter
3.0)
UsingViewerPPTConverter3.0allowsyoutoconvertPowerPointlesintoJPEGles.ConvertedJPEGlesand
Indexles(.idx)canbesavedtoaUSBmemory.WhentheUSBmemoryinsertedintotheprojector,theseJPEGles
andIndexles(.idx)canbedisplayedwiththeviewerfunctionoftheprojectorwithoutconnectingacomputer.
NOTE:
WhenViewerPPTConverter3.0hasbeeninstalled,oncestartViewerPPTConverter3.0oncewiththeprivilegeusedforinstallation.
ThenexitfromViewerPPTConverter3.0withoutdoinganything.
•Starting
ClickWindow’s[Start]→[AllPrograms]→[NECProjectorUserSupportware]→[ViewerPPTConverter3.0]→[ViewerPPT
Converter3.0],inthatorder.
NOTE:
• WheninstallingViewerPPTConverter3.0ontoacomputerthathasPowerPointinstalled,ViewerPPTConverter3.0isautomati-
callyregisteredasaPower-Pointadd-in.
ItisnecessarytocancelViewerPPTConverter3.0add-inbeforeuninstallingViewerPPTConverter3.0.
RefertoViewerPPTConverter3.0Helptounregistertheadd-in.
• Theprojectordoesnotsupporttheadd-in's“RunSlideShow”.
Converting PowerPoint files and saving them to a USB memory
1. InserttheUSBmemoryintotheUSBportofthecomputer.
2. OnWindows,click“Start”→“Allprograms”→“NECProjectorUserSupportware”→“ViewerPPTConverter
3.0”→“ViewerPPTConverter3.0”.
Viewer PPT Converter 3.0 will start.
3. Click“Brows...”andselectaPowerPointleyouwishtoconvert,andthenclick“Open”.
4.Click“Next”.
