3. Convenient Features

 Displaying Two Pictures at the Same Time

Theprojectorhasafeaturethatallowsyoutoviewtwodifferentsignalssimultaneously.Youhavetwomodes:PIP

modeandPICTUREBYPICTUREmode.

Fromthemenuyoucanselect[SETUP]→[BASIC]→[PIP/PICTUREBYPICTURE].

The[PIP/PICTUREBYPICTURE]menuitemhasthefollowingthreeoptions:MODE,POSITION,andSOURCE.

Usetheorbuttontoselect[MODE],[POSITION]or[SOURCE]andpresstheENTERbutton.

Selecting the PIP or PICTURE BY PICTURE Mode [MODE]

Thisoptionallowsyoutoselecttwomodes:PIPandSIDEBYSIDE.

Usetheorbuttontoselect[PIP]or[PICTUREBYPICTURE]andpresstheENTERbutton.

PIP:Thisoptionallowsyoutoviewasubpictureinthemainpicture.

Main picture

Sub


PICTUREBYPICTURE:Thisallowsyoutoviewtwopicturessidebyside.

Main picture Sub picture

NOTE:

• Themainpicturewillbedisplayedontheleftsideandthesubpictureontherightside.

• ThemainpicturesignalsupportstheCOMPUTER1,COMPUTER2,andCOMPUTER3connectors.

 ThesubpicturesignalsupportstheVIDEOINandS-VIDEOINconnectors.

• ThemainpicturesupportsanRGBsignalwitharesolutionof1280×1024pixelsorless.
