3. Convenient Features
7. Inputthepasswordtothepasswordinputboxdisplayedbytheoperationatstep3onpage60.
8. Click[Connect].
ThenetworkprojectorfunctionworksandthescreenofWindows7isprojectedfromtheprojector.
• Iftheresolutionofyourcomputer’sscreenisdifferentfromtheprojector’sscreenresolution,theNETWORK
PROJECTORfunctionmaynotwork.Ifthishappens,changetheresolutionofthecomputer’sscreentolower
resolutionthantheonedisplayedatStep3onpage60.
NOTE:Whenthenetworkprojectorfunctionworks,thebackgroundcolorofthedesktopchangestoblack.Whenthenetwork
projector function is stopped, the original background color is restored.
Reference:IftheprojectorcannotbefoundatStep5,click[→Entertheprojectoraddress].Then,inputthe“Networkaddress”
(Inputexample:http://10.32.97.61/lan)and“Projectorpassword”(Inputexample:82291627)displayedinthescreenprojected
from the projector.
ExitingtheNetworkProjectorOperation
1. Click[Projecting:PH1000Series]intheWindowsVistataskbar.
2. Click[Disconnect].
TheNetworkProjectorfunctionisstopped.
3. PresstheSOURCEbuttonoftheprojectortoselectaninputterminalotherthan[NETWORK].
Whenusingtheremotecontrol,pressabuttonotherthantheNETWORKbutton.
