192
8. User Supportware
•Stoppingorresumingthetransmissionofimages
Thetransmissionofthescreenofthecomputertotheprojectorcanbetemporarilystoppedandthenresumed.
1 Clicktheprojectoricon( )ontheWindowstaskbar.
Apop-upmenuwillbedisplayed.
2 Click[StopSending].
Theprojectoricononthetaskbarwillchange( → ).
NOTE:
Evenifthescreenofthecomputerischangedinthisstatus,theimageprojectedfromtheprojectordoesnotchange.
Tomanipulatethescreenthatshouldnotbedisclosed(projectedfromtheprojector),stoptransmission.
3 Clicktheprojectoricon( )ontheWindowstaskbar.
Apop-upmenuwillbedisplayed.
4 Click[StartSending].
Theprojectoricononthetaskbarwillchange( → ).
Thetransmissionofthescreenforthecomputerwillberesumed,andthecurrentscreenofthecomputerwillbe
projected from the projector.
•Endthetransmissionofimages
ExitImageExpressUtility2.0.
1 Clicktheprojectoricon( )ontheWindowstaskbar.
Apop-upmenuwillbedisplayed.
2 Click[Exit].
