160
6. Installation and Connections
COMPUTER 2 IN
COMPUTER 3 IN
COMPUTER 1 IN
Computercable(VGA)(supplied)
TominiD-Sub15-pinconnector
ontheprojector.Itisrecommend-
edthatyouuseacommercially
availabledistributionamplierif
connectingasignalcablelonger
thanthecablesupplied.
NOTE:ForMacintosh,useacommerciallyavailablepinadapter(not
supplied)toconnecttoyourMac’svideoport.
RGB-to-BNCcable(not
supplied)
Making Connections
Theprojectorcanbeconnectedtoacomputerusingthecomputercable,a5xBNCcable,HDMIcableorDisplayPort
cable.
Preparecommerciallyavailablecablesforconnection.
Analog RGB signal connection
• Connectthecomputercablebetweenthecomputer’sdisplayoutputconnector(miniD-Sub15-pin)andtheprojector’s
Computer1orComputer2videoinputconnector.
• Whenconnectingthecomputer’sdisplayoutputconnector(miniD-Sub15-pin)andtheprojector’sComputer3
videoinputconnector,useaBNCcable(5-core)→miniD-Sub15-pinconvertercable.
• Tooutputaudiofromthecomputer,usecommerciallyavailableaudiosystem.
• Selectthesourcenameforitsappropriateinputconnectorafterturningontheprojector.
Inputconnector
SOURCEbuttonontheprojector
cabinet
Buttonontheremotecontrol
COMPUTER1IN COMPUTER1 COMPUTER1
COMPUTER2IN COMPUTER2 COMPUTER2
COMPUTER3IN
COMPUTER3
COMPUTER3
