1
Projector
1. Introduction
1 What’s in the Box?
Makesureyourboxcontainseverythinglisted.Ifanypiecesaremissing,contactyourdealer.
Pleasesavetheoriginalboxandpackingmaterialsifyoueverneedtoshipyourprojector.
Power cord stopper (79TM1111)
Anti-theft cap for LAN unit (for optional wireless LAN unit)
(79TM1091)
NEC Projector CD-ROM
User’s manual (PDF)
(7N951662)
• ImportantInformation(7N8N2111)
• QuickSetupGuide(7N8N2121/7N8N2131)
• Japaneseuser’smanual(7N8N2141)
• Japanesequickstartguide(7N8N2151)
• Warranty(forJapan)
• Limitedwarranty(forNorthAmerica)
• Registrationcard(forNorthAmerica)
For customers in Europe:
YouwillndourcurrentvalidGuaranteePolicyonourWebSite:
www.nec-display-solutions.com
Remote control
(7N900961)
AAalkalinebatteries
(x2)
Dust cap for lens
* The projector is shipped without a lens. For
thetypesoflensandthrowdistances,see
page 209.
