97
5. Using On-Screen Menu
List of Menu Items
Somemenuitemsarenotavailabledependingontheinputsource.
MenuItem Default Options
SOURCE
COMPUTER1 *
COMPUTER2 *
COMPUTER3 *
HDMI *
DisplayPort *
VIDEO *
S-VIDEO *
VIEWER *
NETWORK *
SLOT
ENTRYLIST
TESTPATTERN
ADJUST
MODE STANDARD STANDARD,PROFESSIONAL
PRESET *
HIGH-BRIGHT,PRESENTATION,VIDEO,MOVIE,GRAPHIC,
sRGB,DICOMSIM.
DETAILSETTINGS
GENERAL
REFERENCE *
HIGH-BRIGHT,PRESENTATION,VIDEO,MOVIE,GRAPHIC,
sRGB,DICOMSIM.
GAMMA
CORRECTION
DYNAMIC,NATURAL,BLACKDETAIL
SCREENSIZE*
1
* LARGE,MEDIUM,SMALL
COLOR
TEMPERATURE*
2
* 5000,6500,7800,8500,9300,10500
DYNAMIC
CONTRAST
* OFF,ON
WHITEBALANCE
CONTRASTR 0
CONTRASTG 0
CONTRASTB 0
BRIGHTNESSR 0
BRIGHTNESSG 0
BRIGHTNESSB 0
COLOR
CORRECTION
RED 0
GREEN 0
BLUE 0
YELLOW 0
MAGENTA 0
CYAN 0
CONTRAST 50
BRIGHTNESS 50
SHARPNESS 10
COLOR 50
HUE 0
RESET
OPTIONS
CLOCK *
PHASE *
HORIZONTAL *
VERTICAL *
BLANKING * TOP,BOTTOM,LEFT,RIGHT
OVERSCAN * AUTO,0[%],5[%],10[%]
ASPECTRATIO
*
(COMPUTER1/2/3)AUTO,4:3,5:4,16:9,15:9,16:10,
NATIVE
*
(COMPONENT/VIDEO/S-VIDEO)AUTO,4:3,LETTERBOX,
WIDESCREEN,ZOOM
*
(COMPONENT/VIDEO/S-VIDEO)AUTO,4:3WINDOW,
LETTERBOX,WIDESCREEN,4:3FILL
RESOLUTION * –
VIDEO
NOISE
REDUCTION
RANDOMNR * OFF,LOW,MEDIUM,HIGH
MOSQUITONR OFF OFF,LOW,MEDIUM,HIGH
BLOCKNR OFF OFF,ON
DEINTERLACE AUTO AUTO,VIDEO,FILM
3DY/CSEPARATION ON OFF,ON
DETAILENHANCEMENT *
SIGNALTYPE RGB RGB,COMPONENT
VIDEOLEVEL AUTO AUTO,NORMAL,ENHANCED
LENSMEMORY
STORE
MOVE
RESET
* Theasterisk(*)indicatesthatthedefaultsettingvariesdependingonthesignal.
*1 The[SCREENSIZE]itemisavailablewhen[DICOMSIM.]isselectedfor[REFERENCE].
*2 When[PRESENTATION]or[HIGH-BRIGHT]isselectedin[REFERENCE],the[COLORTEMPERATURE]isnotavailable.
•Basicmenuitemsareindicatedbyshadedarea.
