8. User Supportware
Installation for Macintosh software
ImageExpressUtility2forMacsupportsMacOSX.
1. ConnectyourMacintoshcomputertotheinternetandvisitourwebsite(http://www.nec-display.com/dl/en/
index.html).
2. Download“ImageExpressUtility2forMacOS(Intel)”or“ImageExpressUtility2forMacOS(PowerPC)”
from“Download”andsavean“.exe”letoyourcomputer.
File name is different depending on the version of the software program.
3. Movethe“ImageExpressUtility2”folderto“Applications”folderusingadrag-and-dropoperation.
TIP:
•Uninstallingasoftwareprogram
1. Putthe“ImageExpressUtility2”foldertotheTrashicon.
2. PutthecongurationleofImageExpressUtility2totheTrashicon.
• ThecongurationleofImageExpressUtility2islocatedin“/user/yourusername/library/Preferences/jp.co.
nec.nevt.ImageExpressUtility.plist”.
