5
1. Introduction
Rear
CAUTION:
PartsoftheprojectormaybecometemporarilyheatediftheprojectoristurnedoffwiththePOWERbuttonorifthe
ACpowersupplyisdisconnectedduringnormalprojectoroperation.
Usecautionwhenpickinguptheprojector.
RemoteSensor(locatedonthe
front and the rear)
(→ page 9)
Ventilation (inlet)
HorizontalAdjustmentKnob
Filter Cover (→ page 174,182)
Ventilation (outlet)
Heated air is exhausted from here.
Lamp Cover (1)
(→ page 180,181)
Lamp Cover (2)
(→ page 180,181)
StackingColumn
SecurityLockingPin
AdjustableTiltFoot
(→ page 22)
Handle
