82
4. Using the Viewer
Viewer option settings
•SLIDESETTING
Setsstillimagesorslides.
Name Options Description
SCREENSIZE BESTFIT Displaystheimagewithitsaspectratiointheprojector’sdisplay-
ablemaximumresolution.
ACTUALSIZE Displaystheimageinitsactualsize.
PLAYMODE MANUAL Selectsmanualplay.
AUTO Selectsautoplay.
INTERVAL 5-300seconds Specifies interval time when [AUTO] is selected for PLAY
MODE.
REPEAT Checkmark Turnsonorofftherepeatfunction.
TIP
• Toplayoneormoreslides,placethoselesintoafolder.
