108

5. Using On-Screen Menu

AdjustingHorizontal/VerticalPosition[HORIZONTAL/VERTICAL]

Adjuststheimagelocationhorizontallyandvertically.

- Animagecanbedistortedduringtheadjustmentof[CLOCK]and[PHASE].Thisisnotmalfunction.

- Theadjustmentsfor[CLOCK],[PHASE],[HORIZONTAL],and[VERTICAL]willbestoredinmemoryforthe

currentsignal.Thenexttimeyouprojectthesignalwiththesameresolution,horizontalandverticalfrequency,

itsadjustmentswillbecalledupandapplied.

 Todeleteadjustmentsstoredinmemory,fromthemenu,youselect[RESET]→[CURRENTSIGNAL]andreset

theadjustments.

[BLANKING]

Adjuststhedisplayrange(blanking)atthetop,bottom,leftandrightedgesoftheinputsignal.

SelectingOverscanPercentage[OVERSCAN]

Selectoverscanpercentage(Auto,0%,5%and10%)forsignal.

Projected image

Overscanedby10%

NOTE:

• The[OVERSCAN]itemisnotavailable:

 -when[NATIVE]isselectedfor[ASPECTRATIO].

 -when[VIEWER]or[NETWORK]isselectedfor[SOURCE]
