193
8. User Supportware
Holding Conferences
•Holdingconferences
1 Followsteps1through4in“Connectingprojector”of“SendingImagestoProjector”(→page190).
Thescreenofyourcomputerwillbeprojectedfromtheprojector.
•Disclosealetotheparticipantsoftheconference.
NOTE:
Todisclosealetotheparticipants,selectioncanbemadeonlyinfolderunits.
Therefore,afolderonlyhavinglesthatcanbedisclosedtotheparticipantsmustbecreatedinadvance.
1 Clicktheprojectoricon( )ontheWindowstaskbar.
Apop-upmenuwillbedisplayed.
2 Beforeclicking[SendtoPCandProjector],checkthatthereisa“•”markapplied.
3 Clickthe[ImageExpressUtility2.0]buttononthetaskbar.
Thepresenterwindowwillbeopened.
4 Click[SelectFolder].
4
Click
