Nec PX700W [171/244] 1 mounting the optional lens

157

6. Connecting to Other Equipment

 Mounting the Optional Lens

Fiveseparatebayonetstylelensescanbeusedwiththisprojector.ThedescriptionsherearefortheNP27ZLlens.

Mountotherlensesinthesamemanner.

NOTE:

• Theprojectorandlensesaremadeofprecisionparts.Donotsubjectthemtoshockorexcessiveforces.

• Removetheseparatelysoldlenswhenmovingtheprojector.Ifnot,thelenscouldbesubjecttoshockwhiletheprojectorisbeing

moved,damagingthelensandthelensshiftmechanism.

• Turnoffthepowerandwaitforthecoolingfantostopandturnoffthemainpowerswitchbeforemountingorremovingthe

lens.

• Whendismountingthelensfromtheprojector,returnthelenspositiontothehomepositionbeforeturningoffthepower.Failureto

dosomaypreventthelensfrombeingmountedordismountedbecauseofnarrowspacebetweentheprojectorandthelens.

• Nevertouchthelenssurfacewhiletheprojectorisoperating.

• Beverycarefulnottoletdirt,grease,etc.,onthelenssurfaceandnottoscratchthelenssurface.

• Performtheseoperationsonaatsurfaceoverapieceofcloth,etc.,topreventthelensfromgettingscratched.

• Whenleavingthelensofftheprojectorforlongperiodsoftime,mountthedustcapontheprojectortopreventdustordirtfrom

getting inside.

• Ifyouhavemultipleprojectors,becarefulofthefollowing:

- TheNP25FL,NP26ZL,andNP27ZLlensesaredesignedexclusivelyforthismodeloftheprojector.Theselensesarenotavail-

able on other projector models.

- TheotherNECoptionallensesarenotavailableonthismodeloftheprojectorexcept:

 NC-60LS12Z,NC-60LS13Z,NC-60LS14Z,NC-60LS16Z,NC-60LS17Z,NC-60LS19Z,NC-60LS24Z,NC-60LS39Z.

Before mounting the lens:

• PrepareaPhillipsscrewdriver(plus-head)

• Removethedustcapfromtheprojector.

TIP:

• Theprojectorcomeswiththedustcapatthetimeofshipment

Mounting the lens

1. Removethelensshroud.

(1) Loosen two screws.

Lens release

lever

Safetylever

Lens shroud
