171
6. Installation and Connections
ExampleofwirelessLANconnection
(NetworkType→Infrastructure)
(→page139)
PC with wireless LAN card
inserted
PCwithbuilt-inwirelessLAN
function
WiredLAN
Wirelessaccesspoint
USBWirelessLANUnit
Toenabledirectcommunication(i.e.,peer-to-peer)betweencomputersandprojectors,youneedtoselecttheAd
Hocmode.(→page139)
PC with wireless LAN card
inserted
PCwithbuilt-inwirelessLAN
function
ExampleofwirelessLANconnection(NetworkType→AdHoc)
USBWirelessLANUnit
