xi
LAN
Intel
®
I218-V Gigabit LAN- Dual interconnect between the integrated
Media Access Controller (MAC) and physical layer (PHY)
Anti-surge LANGuard
ROG GameFirst III
Wireless / Bluetooth
Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz up
to 1300 Mb/s transfer speed
Bluetooth v4.0
SupremeFX
High Definition Audio
ROG SupremeFX 2014 8-Channel High Definition Audio
CODEC
- SupremeFX Shielding Technology
- ELNA
®
Premium audio capacitors
- Content Protection for Full Rate lossless DVD Audio, Blu-ray
DVD, and HD-DVD audio content playback
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features
- Sonic SoundStage
- Sonic SenseAmp
- Sonic Studio
- Sonic Radar II
- DTS Connect
USB
Intel
®
X99 Express Chipset - supports Asus USB 3.0 Boost:
- 4 x USB 3.0 ports ( at mid-board [red])*
- 6 x USB 2.0 ports (2 ports at back panel, 4 ports at mid-board)**
ASMedia
®
USB 3.0 controller:
- 10 x USB 3.0 ports (at back panel [blue])**
* 2 x USB2.0 ports at mid-board shares with ROG extension (ROG_EXT)
port.
** USB3_E910 ports at back panel will be disabled when the PCIE_X4_1
slot is occupied by an X4 bandwidth device
Back Panel I/O Ports
1 x Clear CMOS button
1 x ROG Connect On/Off switch
1 x PS/2 keyboard/mouse combo port
2 x USB 2.0 ports (top port for KeyBot, bottom port for ROG
Connect)
10 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and
Bluetooth v4.0)
1 x Optical S/PDIF out
5 x Gold-plated audio jacks
(continued on the next page)
RAMPAGE V EXTREME specifications summary
