ASUS RAMPAGE V EXTREME
3-37
Chapter 3
EHCI Hand-off [Disabled]
This item is set to [Disabled] by default for the EHCI (enhanced host controller interface)
support by EHCI drivers in operating systems.
[Disabled] Support for EHCI using the EHCI drivers for operating systems with EHCI
support.
[Enabled] Support for EHCI using the BIOS for operating systems without EHCI
support.
USB Single Port Control [Disabled]
Allows you to enable or disable the individual USB ports.
Conguration options: [Enabled] [Disabled]
Refer to the Motherboard layout section for the location of the USB ports.
