Asus rog rampage v extreme/u3.1 [17/230] The tools and components in the table above are not included in the motherboard package

xvii

Installation tools and components

1 set of screws Philips (cross) screwdriver

PC chassis Power supply unit

Intel LGA 2011-3 CPU Intel LGA 2011-3 compatible CPU Fan

DDR4 DIMM SATA hard disk drive

Graphics card SATA optical disc drive (optional)

The tools and components in the table above are not included in the motherboard package.
