Chapter 4: Software support
Chapter 4
Adjusting the DRAM Power
DRAM-chCD Voltage Frequency
AllowsyoutoadjusttheDRAMswitchingfrequenciesforchannelsCandDofthe
DRAM.
DRAM-chAB Voltage Frequency
AllowsyoutoadjusttheDRAMswitchingfrequenciesforchannelsAandBofthe
DRAM.
DRAM-chCD Current Capability
DRAM-chCDCurrentCapabilityallowsuserstocontrolthetotalpowerrangefor
DRAMchannelsCandD.Ahighervaluecorrelatestoawidertotalpowerrange
andextendstheoverclockingfrequencyrange.
DRAM-chAB Current Capability
DRAM-chCDCurrentCapabilityallowsuserstocontrolthetotalpowerrangefor
DRAMchannelsAandB.Ahighervaluecorrelatestoawidertotalpowerrange
andextendstheoverclockingfrequencyrange.
DRAM-chAB Power Phase Control
IncreasethenumberofactivephasesforDRAMchannelsAandBwhenundera
heavysystemloadtogetbettertransientandthermalperformance.Reducethe
numberofactivephasesunderalightsystemloadtoincreaseefciency.
DRAM-chCD Power Phase Control
IncreasethenumberofactivephasesforDRAMchannelsCandDwhenundera
heavysystemloadtogetbettertransientandthermalperformance.Reducethe
numberofactivephasesunderalightsystemloadtoincreaseefciency.
Click or tap to apply the changes
Click or tap to undo the changes
TheactualperformanceboostmayvarydependingonyourCPUspecication.
