ASUS RAMPAGE V EXTREME
4-43
Chapter 4
Sonic SenseAmp
SonicSenseAmpisanexclusiveROGinventionthatisabuilt-inheadphoneAMPon
theonboardaudiocircuitwiththreeAMPlevelsadjustment.Itdetectsyourheadphone’s
impedanceandadjuststhebuilt-inAMPaccordingly.
SonicSenseAmponlyworksonfrontpanel.
Whenyouplugaheadphoneintothefrontheadphonejack,SonicSenseAmpdisplaysapop-
upwindowthatdisplays“Detectingheadphoneimpedance”.
Afterdetectingtheheadphone’simpedance,SonicSenseAmpdisplaysanotherpop-up
windowsimilartotheoneshownbelow.
RefertothetablebelowonthebehaviorofSonicSenseAmpwhenadjustingtheimpedance
ofthedetectedheadphone:
65 ohm or below
AmplifyLevelisautomaticallysetatPerformance
65 ohm to 150 ohm
AmplifyLevelisautomaticallysetatPowerful
> 150 ohm
AmplifyLevelisautomaticallysetatExtreme
Other device
Thedevicepluggedindetectedasotherdevice
