Energy Processing Unit (EPU)
EPUisareal-timesystempower-savingchipthatautomaticallydetectsthecurrentsystem
loadandintelligentlymoderatespowerusage.Itofferssystem-wideenergyoptimization,
reducesfannoise,andextendsthelifespanofyourhardwarecomponents.
Using EPU
Auto
Move the sliders to
adjust monitor and
system sleep time
Tick to enable
Away Mode
Click or tap to
select a fan profile
Click or tap
to apply the
adjustments
Click or tap to undo the
adjustments
Click or tap to apply the
default settings
Tick to select Voltage Decrement setting
Performance
Click or tap to apply the adjustments
Click or tap to undo the adjustments
Click or tap to apply the default settings
Move the sliders to adjust monitor and system sleep timeTick to enable Away Mode
