Chapter 1: Product introduction
Chapter 1
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket
support (Optional)
2 4 8
CORSAIR CMD16GX4M4A2666C14 16GB(4GB*4) SS - - 14-16-16-35 1.2V • •
CORSAIR CMD32GX4M4A2666C14 32GB(8GB*4) DS - - 14-16-16-35 1.2V • •
CORSAIR CMK16GX4M4A2666C15 16GB(4GB*4) SS - - 15-17-17-35 1.2V • •
CORSAIR CMK32GX4M4A2666C15 32GB(8GB*4) DS - - 15-17-17-35 1.2V • •
CORSAIR CMK16GX4M4A2666C14R 16GB(4GB*4) SS - - 14-16-16-35 1.2V • •
CORSAIR CMK32GX4M4A2666C14R 32GB(8GB*4) DS - - 14-16-16-35 1.2V • •
G.SKILL F4-2666C15Q-16GRR 16GB(4GB*4) SS 15-17-17-36 1.2V • •
G.SKILL F4-2666C15Q-32GRR 32GB(8GB*4) DS 15-17-17-36 1.2V • •
DDR4 2666 MHz capability
