ASUS RAMPAGE V EXTREME
4-21
Chapter 4
Set a schedule for
the BIOS Update
download
Click or tap to
check for a new
BIOS update
available for
download
Click or tap
to cancel the
download
schedule setting
Click or tap
to apply the
download
schedule setting
USB BIOS Flashback
USBBIOSFlashbackallowsyoutocheckandsavethelatestBIOSversiontoaUSB
storagedevice.UsethisutilitytoquicklycheckforthelatestavailableBIOSandsettheBIOS
downloadschedule.
Launching USB BIOS Flashback
TolaunchUSBBIOSFlashback,clickortap onthetop-rightcorneroftheAISuite3
mainmenu,thenselect USB BIOS Flashback.
USBBIOSFlashbackisavailableonlyinselectedmotherboardmodels.
Scheduling the BIOS download
1. IntheDownloadSettingeld,tickSchedule (days)thenselectthenumberofdaysto
changehowfrequentlythesoftwarechecksforanupdatedBIOS.
2. ClickortapApplytosavetheBIOSdownloadschedule.ClickortapCanceltocancel
thedownloadschedule.
Using USB BIOS Flashback
