Chapter 3: BIOS setup

Chapter 3

CPU System Agent Voltage Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU System Agent Voltage Offset [Auto]

This item allows you to set the amount of voltage fed to the system agent of the

processor including its PCIE controller and power control unit (PCU). Setting a high

system agent voltage may enhance the overclocking capability.Use the <+> or <-> key

to adjust the value. The values range from 0.001V to 0.999V at 0.001V increment.

CPU SVID Support [Auto]

Set this item to stop the CPU from communicating with the external voltage regulator. Disable

this item when you overclock your system.

Conguration options: [Auto] [Disabled] [Enabled]

CPU Input Voltage [Auto]

This item allows you to set the input voltage for the processor by the external voltage

regulator. Use the <+> or <-> key to adjust the value.

Conguration options: [0.800V] - [3.400V]

DRAM SVID Support [Auto]

Set this item to stop the CPU from communicating with the external voltage regulator. Disable

this item when you overclock your system.

Conguration options: [Auto] [Disabled] [Enabled]

DRAM Voltage (CHA, CHB) / (CHC, CHD) [Auto]

This item allows you to set the voltage for the system memory. Use the <+> or <-> key to

adjust the value. The values range from 0.80V to 1.90V at 0.010V increment.

According to Intel

CPU specications, DIMMs with voltage requirement over 1.65 V may

damage the CPU permanently. We recommend that you install the DIMMs with the voltage

requirement below 1.65 V.

PCH Core Voltage [Auto]

This item allows you to congure the core voltage for the PCH (platform controller hub). Use

the <+> or <-> key to adjust the value. The values range from 0.70V to 1.80V at 0.00635V

increment.

PCH I/O Voltage [Auto]

This item allows you to congure the I/O voltage for the PCH (platform controller hub). Use

the <+> or <-> key to adjust the value. The values range from 1.20V to 2.20V at 0.00635V

increment.
