ASUS RAMPAGE V EXTREME
4-23
Chapter 4
Push Notice
Thisutilityallowsyouviewthedetailedstatusofyoursystemonyoursmartdevice.Youcan
alsosendmessagestoyoursmartdeviceusingthisutility.
Beforeusingthisutility,ensurethatyourcomputerispairedwithyoursmartdevice.For
moreinformationonpairing,refertothePairing your computer and smart device
section.
Launching Push Notice on your computer
TolaunchPushNotice,clickortap onthetop-rightcorneroftheAISuite3main
menu,thenselectPush Notice.
Push Notice screen
Click or tap to enable Push Notice
Click or tap to
apply the settings
Click or tap to
discard the settings
Tick to select the
smart device
YoucanalsoenablethePushNoticeviathePushNoticeshortcutonthelower-rightcorner
ofyourscreen.Todothis,clickortap<< thenclickortap thenselect .
Pairing your computer and smart device
Topairyourcomputerandsmartdevice:
1. Onyoursmartdevice,tap
Push Notice
tolaunchPushNotice.
2. TapPush Scan thentapthenameofyourcomputerthatyouwanttopairwith.
Topairyourcomputerandsmartdevice,ensurethatbothareconnectedtothesame
wirelessnetwork.
