ASUS RAMPAGE V EXTREME
4-11
Chapter 4
DIGI+ Power Control
ASUSDIGI+PowerControlfeaturestherevolutionaryandinnovativedigitalVRMandDRAM
voltagecontrollers.Thesecontrollersofferultra-precisememoryandvoltagetuningfor
optimalsystemefciency,stability,andperformance.
Thefollowingscreensareforreferenceonly.Congurationoptionsvariesdependingonthe
motherboardmodel.
Click or tap to
apply the changes
Click or tap to undo
the changes
VRM Phase Control
Increasethenumberofactivephasesunderaheavysystemloadtogetbetter
transientandthermalperformance.Reducethenumberofactivephasesundera
lightsystemloadtoincreaseefciency.
VRM Frequency
Enablesspreadspectrumtoenhancesystemstability.
CPU OTP Capability
IncreasetheCPU’smaximumoperatingtemperaturetoextendtheoverclocking
tolerancetoincreaseoverclockingpotential.
Vcore Current Capability
VcoreCurrentCapabilityallowsuserstocontrolthetotalpowerrangefor
overclocking.Ahighervaluecorrelatestoawidertotalpowerrangeandextends
theoverclockingfrequencyrange.
Vcore Load-line Calibration
VcoreLoad-lineCalibrationadjuststhevoltagerangeoftheCPUload-line.
Increasethevalueforbetterperformanceanddecreasethevalueforbetter
efciency.
VRM Duty Control
VRMDutyControladjuststheoperatingcurrentandthermalconditionofeach
phasecomponent.
Active Frequency Mode
ActiveFrequencyModeallowsyoutoenhancethepowersavingconditionofthe
CPU.TickONtogetaquickertransientresponsewhilesavingtheCPUpower.
Click or tap to switch
between screens
