2-14
Chapter 2: Basic Installation
Chapter 2
2.2 BIOS update utility
USB BIOS Flashback
USBBIOSFlashbackallowsyoutoeasilyupdatetheBIOSwithoutenteringtheexisting
BIOSoroperatingsystem.SimplyinsertaUSBstoragedevicetotheUSBportspecially
allocatedfortheUSBBIOSFlashbackfeaturethenpresstheROGConnectbuttonforthree
seconds.TheBIOSwillbeupdatedautomatically.
TouseUSBBIOSFlashback:
1. DownloadthelatestBIOSlefromtheASUSwebsite
2. ExtractandrenametheBIOSimageletoR5E.CAP.
3. Copy R5E.CAPtotherootdirectoryoftheUSBashdiskdrive.
4. TurnoffthesystemandinserttheUSBstoragedevicetotheROGConnectport.
5. PresstheROGConnectbuttonandreleasewhenaashinglightappears,which
indicatesthattheBIOSFlashbackfunctionisenabled.
6. Waituntilthelightgoesout,indicatingthattheBIOSupdatingprocessiscompleted.
FormoreBIOSupdateutilitiesinBIOSsetup,refertotheUpdating BIOS section in
Chapter 3.
• DONOTunplugportabledisk,powersystem,orpresstheCLR_CMOSbuttonwhile
theBIOSupdateisongoing,otherwisetheupdatewillbeinterrupted.Incaseof
interruption, please follow the steps again.
• UpdatingtheBIOSmayhaverisks.IftheBIOSprogramisdamagedduringthe
process and results in the system’s failure to boot up, please contact your local ASUS
Service Center.
USB BIOS Flashback/ ROG Connect port
