Asus rog rampage v extreme/u3.1 [207/230] Chapter 4

ASUS RAMPAGE V EXTREME

4-57

Chapter 4

Synchronizing backup files

Aftercreatingajunctionpoint,RAMDiskautomaticallycreatesabackupfolderinthele’s

originallocation.UseRAMDisktomanuallysynchronizeupdateswiththesebackuples.

Click or tap Synchronize to

update your files
