Chapter 4: Software support
Chapter 4
Fan Xpert 3
ASUSFanXpert3providescustomizablesettingsofyourfansforacoolerandquieter
computingenvironment.Withitsautomaticfantuningfeature,ASUSFanXpert3
automaticallytweaksthesettingsofCPUandchassisfanstocreatethebestcoolingproles.
ASUSFanXpert3alsosupportshardwarelevelPWM/DCcombomodefortheCPUand
chassisfans.YoucanalsoreducetheCPUfanspeedbelowthedefaultminimumfora
noiselessoperationduringlightloads.
Click or tap
a screen to
select the
type of fan
that you want
to customize
Click or tap to set
the fan’s speed to
silent mode
Click or tap to set the
balanced configuration
between the fan’s noise level
and speed
Click or tap to increase the
fan’s speed for a high cooling
capability
Click or tap to
maximize the
fan speed
Click or tap to switch
between CPU and chassis
fan screens
