ASUS RAMPAGE V EXTREME
1-5
Chapter 1
1.1.4 ASUS special features
AI Suite 3
With its user-friendly interface, ASUS AI Suite 3 consolidates all the exclusive ASUS features
into a single software package. It allows you to monitor fan speeds, voltages, and sensor
readings.
USB BIOS FlashBack
USB BIOS Flashback offers a hassle-free updating solution for your ultimate convenience.
Simply install a USB storage device containing the BIOS le, press the BIOS Flashback
button for three seconds, and the UEFI BIOS is automatically updated even without entering
the existing BIOS or operating system. It also allows you to regularly check for UEFI BIOS
updates and download the latest BIOS automatically.
