Asus rog rampage v extreme/u3.1 [141/230] Tool menu

ASUS RAMPAGE V EXTREME

3-53

Chapter 3

3.9 Tool menu

The Tool menu items allow you to congure options for special functions. Select an item then

press <Enter> to display the sub menu.

GPU Post

This function allows you to enable the GPU Post feature.

ASUS EZ Flash 2 Utility

Allows you to run ASUS EZ Flash 2. When you press <Enter>, a conrmation message

appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to

conrm your choice.

For more information, see the ASUS EZ Flash 2 Utility section.
