Asus rog rampage v extreme/u3.1 [188/230] Chapter 4

4-38

Chapter 4: Software support

Chapter 4

Remote Keyboard & Mouse

RemoteKeyboard&Mouseallowsyoutouseyoursmartdevice’stouchpanelasaremote

keyboardandmouseforyourcomputer.

Input field

Control keys

Tap to switch between zoom

and magnifier function

Tap to switch between

running tasks and apps

Tap to display the

Start menu

Mouse tap area

Tap to mimic right-

click mouse function

Tap to mimic left-

click function

Slide up/down to scroll
