Asus rog rampage v extreme/u3.1 [113/230] Chapter 3

ASUS RAMPAGE V EXTREME

3-25

Chapter 3

CPU Cache Voltage [Auto]

This item allows you to congure the amount of voltage fed to the CPU uncores including it is

cache. Increase the voltage when conguring a high CPU cache frequency.

Conguration options: [Auto] [Manual Mode] [Offset Mode] [Adaptive Mode]

The following item appears only when you set the CPU Cache Voltage to [Manual Mode].

CPU Cache Voltage Override [Auto]

This item allows you to congure the CPU cache voltage. Use<+> or <->

key to adjust the value. The values range from 0.001V to 1.920V at 0.001V

increment.

The following items appear only when you set the CPU Core Voltage to [Offset Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Cache Voltage Offset [Auto]

This item allows you to congure the CPU cache voltage offset value.

Use<+> or <-> key to adjust the value. The values range from 0.001V to

0.999V at 0.001V increment.

The following items appear only when you set the CPU Core Voltage to [Adaptive Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Cache Voltage Offset [Auto]

This item allows you to congure the CPU cache voltage offset value.

Use<+> or <-> key to adjust the value. The values range from 0.001V to

0.999V at 0.001V increment.

Additional Turbo Mode CPU Cache Voltage [Auto]

This item allows you to set the amount of voltage fed to the CPU cores

when running in turbo mode. Increase the voltage when conguring a high

CPU core frequency. The voltage you set is affected by the offset value.

Use the <+> or <-> keys to adjust the value. The values range from 0.001V

to 1.920 V with a 0.001 V interval.
