4-18
Chapter 4: Software support
Chapter 4
EZ Update
EZUpdateisautilitythatallowsyoutoautomaticallyupdateyourmotherboard’ssoftware,
drivers,orBIOS.
Withthisutility,youcanalsomanuallyupdatetheBIOSandselectthebootlogothatwill
displayduringPOST.
Launching EZ Update
TolaunchEZUpdate,clickortap onthetop-rightcorneroftheAISuite3mainmenu,
thenclick EZ UpdateontheAISuite3mainmenubar.
EZ Update screen
Click or tap to automatically update your
motherboard’s driver, software, and firmware
Click or tap to search
and select the BIOS file
Click or tap to select
a boot logo
Click or tap to
update the BIOS
