4-30
Chapter 4: Software support
Chapter 4
Creating an ASUS account
Ensurethatyouhaveaninternetconnectionbeforeyoucreateanaccount.
TocreateanewASUSaccount:
1. ClickortapCreateaNewAccountonyourPCorsmartdevice.
ThebrowserwilldirectyoutotheASUSwebsite(www.asus.com).
2. FromtheASUSwebsite,clickortapSignUpthenfollowonscreeninstructionsto
completetheregistration.
AloginnoticeisdisplayedwhenyoulaunchWi-Fi
GO!forthersttimeonyourPC.Tostopthis
noticefromappearingagain,tickDon’tremindme
againthenclickGotoLogin.
Logging in
Tolog-inusingyourPC:
1. LaunchWi-FiGO!onyourPC.
2. Fromthelog-inwindow,keyinyourASUSaccountandpassword(A)thenclickLogin
(B).
