Asus rog rampage v extreme/u3.1 [63/230] Probeit

ASUS RAMPAGE V EXTREME

1-45

Chapter 1

1.2.10 ProbeIt

The ROG ProbeIt allows you to detect your system’s current voltage and OC settings. Use a

multimeter to measure the ProbeIt points even during overclocking.

See the illustration below to locate the respective ProbeIt points.

Using ProbeIt

You can connect the multimeter to the motherboard as shown on the following gure.

The illustration above are for reference only, the actual motherboard layout and measure

points location may differ by models.
