ASUS RAMPAGE V EXTREME
4-1
Chapter 4
Software support
4
4.1 Installing an operating system
• ThismotherboardsupportsWindows
®
8/Windows
®
8.132/64-bitandWindows
®
7
32/64-bitoperatingsystems(OS).
• Motherboardsettingsandhardwareoptionsvary.Usethesetupprocedurespresented
inthischapterforreferenceonly.RefertoyourOSdocumentationfordetailed
information.
4.2 Support DVD information
ThecontentsofthesupportDVDaresubjecttochangeatanytimewithoutnotice.Visitthe
ASUSwebsiteatwww.asus.comforupdates.
Chapter 4: Software support
EnsurethatyouhaveanAdministratoraccountbeforerunningthesupportDVDin
Windows
®
7orWindows
®
8/Windows
®
8.1OS.
4.2.1 Running the support DVD
TorunthesupportDVD:
1. PlacetheSupportDVDintotheopticaldrive.
2. IntheAutoPlay dialogbox,clickRun ASSETUP.exe.
IftheAutoPlay dialogboxdoesnotappear,browsethecontentsofthesupportDVDand
double-clickortap\\bin\ASSETUP.EXEtolaunchtheASUS motherboard support
DVD mainmenu.
